Tempered Glass Screen Protector OPP Horizontal Flow Packing Machine

Tempered Glass Screen Protector OPP Horizontal Flow Packing Machine

  • Tempered Glass Screen Protector OPP Horizontal Flow Packing Machine
Tempered Glass Screen Protector OPP Horizontal Flow Packing Machine
Product Details:
Place of Origin: CHINA
Brand Name: CUKKE
Certification: CE
Model Number: ZS-450X
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 5700 per set
Packaging Details: export standard wooden box
Delivery Time: 3 days
Payment Terms: T/T
Supply Ability: 10 sets per day
Contact Now
Detailed Product Description
Weight: 500kg Voltage: Customized
Condition: New Automatic Grade: Automatic
Warranty: 1 Year After-sales Service Provided: Video Technical Support
Power(kw): 4.5 Capacity: 70-80pcs/min
Function: Face Mask Filling Sealing Packing Machine Color: Customizable
Control Mode: PLC
High Light:

4KW Horizontal Flow Packing Machine

,

4KW Flow Packing Machine

,

OPP Screen Protector Packing Machine

Automatic Horizontal Flow Pillow Tempered Glass Screen Protector Packing Machine



★Applications:



Applicable for packing various irregular objects,adhesive objects and solid objects, such as food, including egg rolls,sausages,squids ,instant noodles,snow cakes,preserved fruits,jelly drops etc; others, including soaps, essential balm mini-notebooks,box-packed pens,tapes,medicines etc. It’s widely used.





Machine parameters:



机型(Type) ZS-450X
薄膜宽度(Film width) Max 450mm
制袋长度(Bag length) 80-1000mm
制袋宽度(Bag width) 50-200mm
产品高度(Product height) 5-65mm
膜卷直径(Film roll diameter) Max 300mm
包装速度(Packaging speed) 20-150bag/min
包装材料(Packaging materials) OPP, OPP/PE, OPP/CPP,PT/PE,KOP/CPP,ALU-FILM
电源规格(Power) 220V,50/60Hz,4.0KW
机器尺寸(Machine size) (L)4075×(W)960×(H)1400
机器重量(Machine weight) 600Kg







★Features:

Fully servo control, bag length and bag cutting can be set in one step, so time saving and film saving.

With colour HMI touch screen control, easy parameter setting. And up to 100 kinds of packaging parameters storage capacity, being more convenient for different product packing.

Fault self-diagnostic function, fault could be clear at a glance.

High sensitivity photocell for tracking, and digital input for sealing position, which make the sealing more accurate.

Separate PID temperature control, being fitter to various packing Material.

Positioned stop function, without sticking cutter or wasting film.

It makes the machine more reliable and more convenient for maintenance by having a simple transmission system..

8. Cutter automatically contrarotates when product cut, machine directly resumes to work after reboot without any extra setting, and being able to protect the cutter base and be safer if any breakdown.

9. Without verpacking film, it will stop working automatically.

10. Three model options: film conveyor type ( products put on the film directly ), belt type ( convenient to butt joint with other production line ), and push-rod type.

11.The optional model has full pull packaging film type (product directly on packaging film), belt type (convenient butt joint production line) and push-rod type three kinds of structure models.
