| Place of Origin: | CHINA |
| Brand Name: | CUKKE |
| Certification: | CE |
| Model Number: | ZS-580X |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 5700 per set |
| Packaging Details: | export standard wooden box |
| Delivery Time: | 3 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 sets per day |
| Weight: | 500kg | Voltage: | Customized |
|---|---|---|---|
| Condition: | New | Condition: | New |
| Automatic Grade: | Automatic | Automatic Grade: | Automatic |
| Warranty: | 1 Year | Warranty: | 1 Year |
| After-sales Service Provided: | Video Technical Support | After-sales Service Provided: | Video Technical Support |
| Power(w): | 4.5 | Power(w): | 4.5 |
| Capacity: | 70-80pcs/min | Capacity: | 70-80pcs/min |
| Function: | Face Mask Filling Sealing Packing Machine | Function: | Face Mask Filling Sealing Packing Machine |
| Color: | Customizable | Color: | Customizable |
| Control Mode: | PLC | Control Mode: | PLC |
| High Light: | 580mm Horizontal Flow Packaging Machine,580mm Pillow Bag Packaging Machine,120bag/min Pillow Bag Packaging Machine |
||
Automatic Horizontal Flow Pillow Wristbands Packing Machine
1.Efficient: Bag-making, filling, sealing, cutting, heating, date / lot number achieved in one time.
2.Intelligent: Packing speed and bag length can be set through the screen without part changes.
3.Profession: Independent temperature controller with heat balance enables different packing materials; Dual inverters controller, upgradable PLC system, self-failure diagnosis, double encoder.
4.Characteristic: Automatic stop function, with safe operation and saving the film.
5.Convenient: Low loss, labor saving, easy for operation and maintenance.
6.Adapability: one set of machine can be applicated to different kind of product via optional devices, such as air-filling device, feeding line, etc.
Machine parameters:
| 机型(Model) | ZS-580X |
| 薄膜宽度(Film width) | Max 580mm |
| 制袋长度(Bag length) | 120-1000mm |
| 制袋宽度(Bag width) | 100-250mm |
| 产品高度(Product height) | 5-75mm |
| 膜卷直径(Film roll diameter) | Max 300mm |
| 包装速度(Packaging speed) | 20-120bag/min |
| 包装材料(Packaging materials) | OPP, OPP/PE, OPP/CPP |
| 电源规格(Power) | 220V,50/60Hz,4.25KW |
| 机器尺寸(Machine size) | (L)4210×(W)1070×(H)1400 mm |
| 机器重量(Machine weight) | 650Kg |
Main performance and characteristics:
1.controlled by three servos;
2.touch screen display screen, easy to operate, machine working state clear;
3.can automatically adjust bag length according to material length without manual setting;.
4.reduce the labor intensity of operators and improve production efficiency
5.can store a variety of product parameters and formulations, without repeated settings, download can be used;
